Description

DBA’s Street Series T2 rotor provides all the benefits of DBA’s Street Series direct replacement rotors with the added benefit of performance braking through the introduction of DBA’s patented T2 slot design.

The T2 slot design features precise CNC machined bi-symmetrical slots, resulting in a quieter, more responsive and smoother brake pedal feel. The T2 slot increases the number of exit points, allowing friction dust and gases to escape and enhancing the pad bite.

DBA’s revolutionary universal slot design also eliminates the need for separate left and right slot designs seen in traditional rotor designs.

We recommend the T2 slot design for more intensive braking applications.

T2 is denoted by the suffix (S) in Street Series part numbers.

Specifications

  • Diameter (mm) : 295.6
  • Height (mm) : 53
  • Thickness (mm) : 28
  • Minimum Thickness (mm) : 26
  • Centre Hole (mm) : 68
  • Stud Holes : 6
  • Weight (kg) : 8.62
  • “Kangaroo Paw – 144 diamond and tear drop pillar ventilation system”
  • Minimises brake fade and increases braking effectiveness
  • Increased surface area resulting in greater heat dissipation
  • CBN (Cubic Boron Nitride) machine turned
  • Reduced DTV (Disc thickness variation) and parallelism
  • Less occurrence of brake shudder or brake pedal ‘judder’
  • *Kangaroo Paw is not available on all part numbers, ask your supplier for details

Compatibility

  • 2015-On Nissan Navara DX 023, NP300 (2 Door Cab Chassis) 2.5 litre, QR25DE 14 16V DOHC WT
  • 2015-On Nissan Navara DX 023, NP300 (4 Door Wellside) 2.5 litre, QR25DE 14 16V DOHC WT
  • 2015-On Nissan Navara DX, RX D23, NP300 (2 Door Cab Chassis) 2.3 litre, YS23DDT 14 16V DOHC
  • 2015-On Nissan Navara RX D23, NP300 (2 Door Cab Chassis) 2.3 litre, YS23DDT 14 16V DOHC
  • 2015-On Nissan Navara RX D23, NP300 (4 Door Wellside) 2.3 litre, YS23DDT 14 16V DOHC
  • 2008-2015 Nissan Navara RX D40 (2 Door Cab Chassis) 2.5 litre, YD25DDTI 14 16V DOHC
  • 2009-2015 Nissan Navara RX D40 (4 Door Wellside) 2.5 litre, YD25DDTI 14 16V DOHC
  • 2015-On Nissan Navara RX King Cab D23 NP300 (4 Door Cab Chassis) 2.3 litre, YS23DDT 14 16V DOHC
  • 2015-On Nissan Navara RX King Cab D23 NP300 (4 Door Wellside) 2.3 litre, YS23DDT 14 16V DOHC
  • 2008-2015 Nissan Navara RX, ST-X King Cab D40 (4 Door Utility) 2.5 litre, YD25DDTI 14 16V DOHC
  • 2015-On Nissan Navara SL, ST, ST-X 023, NP300 (4 Door Wellside) 2.3 litre, YS23DDTT 14 16V DOHC
  • 2015-On Nissan Navara SL, ST, ST-X King Cab D23, NP300 (4 Door Wellside) 2.3 litre, YS23DDTT 14 16V DOHC
  • 2009-2015 Nissan Navara ST, ST-X, RX D40 (4 Door Utility) 2.5 litre, YD25DDTI 14 16V DOHC
  • 2015-On Renault Alaskan D23 (2 Door Cab Chassis) 2.3 litre, YS23DDT 14 16V DOHC
  • 2015-On Renault Alaskan D23 (4 Door Wellside) 2.3 litre, YS23DDT 14 16V DOHC

DBA’s Street Series T2 rotor provides all the benefits of DBA’s Street Series direct replacement rotors with the added benefit of performance braking through the introduction of DBA’s patented T2 slot design.

The T2 slot design features precise CNC machined bi-symmetrical slots, resulting in a quieter, more responsive and smoother brake pedal feel. The T2 slot increases the number of exit points, allowing friction dust and gases to escape and enhancing the pad bite.

DBA’s revolutionary universal slot design also eliminates the need for separate left and right slot designs seen in traditional rotor designs.

We recommend the T2 slot design for more intensive braking applications.

T2 is denoted by the suffix (S) in Street Series part numbers.

  • Diameter (mm) : 295.6
  • Height (mm) : 53
  • Thickness (mm) : 28
  • Minimum Thickness (mm) : 26
  • Centre Hole (mm) : 68
  • Stud Holes : 6
  • Weight (kg) : 8.62
  • “Kangaroo Paw – 144 diamond and tear drop pillar ventilation system”
  • Minimises brake fade and increases braking effectiveness
  • Increased surface area resulting in greater heat dissipation
  • CBN (Cubic Boron Nitride) machine turned
  • Reduced DTV (Disc thickness variation) and parallelism
  • Less occurrence of brake shudder or brake pedal ‘judder’
  • *Kangaroo Paw is not available on all part numbers, ask your supplier for details
  • 2015-On Nissan Navara DX 023, NP300 (2 Door Cab Chassis) 2.5 litre, QR25DE 14 16V DOHC WT
  • 2015-On Nissan Navara DX 023, NP300 (4 Door Wellside) 2.5 litre, QR25DE 14 16V DOHC WT
  • 2015-On Nissan Navara DX, RX D23, NP300 (2 Door Cab Chassis) 2.3 litre, YS23DDT 14 16V DOHC
  • 2015-On Nissan Navara RX D23, NP300 (2 Door Cab Chassis) 2.3 litre, YS23DDT 14 16V DOHC
  • 2015-On Nissan Navara RX D23, NP300 (4 Door Wellside) 2.3 litre, YS23DDT 14 16V DOHC
  • 2008-2015 Nissan Navara RX D40 (2 Door Cab Chassis) 2.5 litre, YD25DDTI 14 16V DOHC
  • 2009-2015 Nissan Navara RX D40 (4 Door Wellside) 2.5 litre, YD25DDTI 14 16V DOHC
  • 2015-On Nissan Navara RX King Cab D23 NP300 (4 Door Cab Chassis) 2.3 litre, YS23DDT 14 16V DOHC
  • 2015-On Nissan Navara RX King Cab D23 NP300 (4 Door Wellside) 2.3 litre, YS23DDT 14 16V DOHC
  • 2008-2015 Nissan Navara RX, ST-X King Cab D40 (4 Door Utility) 2.5 litre, YD25DDTI 14 16V DOHC
  • 2015-On Nissan Navara SL, ST, ST-X 023, NP300 (4 Door Wellside) 2.3 litre, YS23DDTT 14 16V DOHC
  • 2015-On Nissan Navara SL, ST, ST-X King Cab D23, NP300 (4 Door Wellside) 2.3 litre, YS23DDTT 14 16V DOHC
  • 2009-2015 Nissan Navara ST, ST-X, RX D40 (4 Door Utility) 2.5 litre, YD25DDTI 14 16V DOHC
  • 2015-On Renault Alaskan D23 (2 Door Cab Chassis) 2.3 litre, YS23DDT 14 16V DOHC
  • 2015-On Renault Alaskan D23 (4 Door Wellside) 2.3 litre, YS23DDT 14 16V DOHC
