Description

DBA’s EnShield technology has been introduced to the Street Series range to provide rust free rotors. The EnShield process begins with a DBA Street Series Direct Replacement rotor, where a zinc/aluminium water-based coating is applied to the entire rotor surface and is then baked on. The result protects the rotor from corrosion and keeps it looking good during its service life.

EnShield alleviates the need to clean rotors prior to installation, saving fitment time and preventing rust!

EnShield rotors are denoted by the suffix (E) in Street Series part numbers.

Specifications

  • Diameter (mm) : 332
  • Height (mm) : 59
  • Thickness (mm) : 32
  • Minimum Thickness (mm) : 30
  • Centre Hole (mm) : 98
  • Stud Holes : 6
  • Weight (kg) : 12.3
  • “Kangaroo Paw – 144 diamond and tear drop pillar ventilation system”
  • Minimises brake fade and increases braking effectiveness
  • Increased surface area resulting in greater heat dissipation
  • CBN (Cubic Boron Nitride) machine turned
  • Reduced DTV (Disc thickness variation) and parallelism
  • Less occurrence of brake shudder or brake pedal ‘judder’
  • *Kangaroo Paw is not available on all part numbers, ask your supplier for details

Compatibility

  • 2015-On Ford Everest UA 4 Door SUV 3.2 litre, PSAT 15 20V DOHC
  • 2016-2018 Ford Everest Trend UA 4 Door SUV 3.2 litre, PSAT IS 20V DOHC
  • 2018-On Ford Ranger Raptor PX 4 Door Wellside 2 litre, YN2S 14 16V DOHC

DBA’s EnShield technology has been introduced to the Street Series range to provide rust free rotors. The EnShield process begins with a DBA Street Series Direct Replacement rotor, where a zinc/aluminium water-based coating is applied to the entire rotor surface and is then baked on. The result protects the rotor from corrosion and keeps it looking good during its service life.

EnShield alleviates the need to clean rotors prior to installation, saving fitment time and preventing rust!

EnShield rotors are denoted by the suffix (E) in Street Series part numbers.

  • Diameter (mm) : 332
  • Height (mm) : 59
  • Thickness (mm) : 32
  • Minimum Thickness (mm) : 30
  • Centre Hole (mm) : 98
  • Stud Holes : 6
  • Weight (kg) : 12.3
  • “Kangaroo Paw – 144 diamond and tear drop pillar ventilation system”
  • Minimises brake fade and increases braking effectiveness
  • Increased surface area resulting in greater heat dissipation
  • CBN (Cubic Boron Nitride) machine turned
  • Reduced DTV (Disc thickness variation) and parallelism
  • Less occurrence of brake shudder or brake pedal ‘judder’
  • *Kangaroo Paw is not available on all part numbers, ask your supplier for details
  • 2015-On Ford Everest UA 4 Door SUV 3.2 litre, PSAT 15 20V DOHC
  • 2016-2018 Ford Everest Trend UA 4 Door SUV 3.2 litre, PSAT IS 20V DOHC
  • 2018-On Ford Ranger Raptor PX 4 Door Wellside 2 litre, YN2S 14 16V DOHC
