Description

  • Tests all 9V to 30V vehicle electrical systems
  • Intelligent identification of voltage & resistance
  • Interchangeable probe and 1m extension cord for difficult to reach areas
  • Powered by 12 or 24V vehicle battery
  • Oscilloscope function for single circuit testing
  • Multimeter mode (measure voltage, resistance & diode)
  • Dual top-mounted LED work lights
  • Back lit 2.4" LCD display
  • Multiple language settings
  • Built-in speaker for warnings & alerts
  • Electrical system tester
  • 5m power cable & 1m probe extension cable
  • Alligator clips
  • Needle point test probe
  • Automotive test probe (1mm diameter flattened tip)
  • Auxiliary grounding clip

Specifications

  • Working voltage DC: Min 9V – Max 30V
  • Working temperature: 0 - 60?C (32 - 140?F)
  • Storage temperature: -40 - 70?C (-40 - 158?F)
  • Power supply: 12V or 24V DC (Vehicle Battery)
  • Max measuring voltage: 100 Volts
  • Min measuring voltage: 0.1 of a Volt
  • Resistance measuring ?: 1.0 ohm ~ 200K ohm
  • Current measuring range: 0 ~ 18 Amps
  • Max continuous current: 18 Amps
  • TFT true color LED display: 2.4"inches (320x240 DPI)

Compatibility

  • Universal Part
  • Tests all 9V to 30V vehicle electrical systems
  • Intelligent identification of voltage & resistance
  • Interchangeable probe and 1m extension cord for difficult to reach areas
  • Powered by 12 or 24V vehicle battery
  • Oscilloscope function for single circuit testing
  • Multimeter mode (measure voltage, resistance & diode)
  • Dual top-mounted LED work lights
  • Back lit 2.4" LCD display
  • Multiple language settings
  • Built-in speaker for warnings & alerts
  • Electrical system tester
  • 5m power cable & 1m probe extension cable
  • Alligator clips
  • Needle point test probe
  • Automotive test probe (1mm diameter flattened tip)
  • Auxiliary grounding clip
  • Working voltage DC: Min 9V – Max 30V
  • Working temperature: 0 - 60?C (32 - 140?F)
  • Storage temperature: -40 - 70?C (-40 - 158?F)
  • Power supply: 12V or 24V DC (Vehicle Battery)
  • Max measuring voltage: 100 Volts
  • Min measuring voltage: 0.1 of a Volt
  • Resistance measuring ?: 1.0 ohm ~ 200K ohm
  • Current measuring range: 0 ~ 18 Amps
  • Max continuous current: 18 Amps
  • TFT true color LED display: 2.4"inches (320x240 DPI)
  • Universal Part
