Description

All Ironman 4x4 coil springs are designed to provide a safe, comfortable ride while also providing additional ground clearance.

Ironman 4x4 coil springs are CNC cold wound and bar peeled for maximum reliability and consistency, every coil spring is ‘shot-blasted’ to ensure long life, preset to its solid height and load tested to avoid spring sag.

All springs are electro-static powder-coated for a gleaming appearance. Available in raised height and perfectly matched to Ironman 4x4 Shock Absorbers.

Specifications

  • Quantity Required: 1
  • Estimated Lift: 40mm
  • Additional Load: Pajero 0-200kg, Challenger 200-400kg, Pajero Sport 15+ 250-500kg
  • 1988-2000 Pajero: Suits long wheel base vehicles or constant load short wheel base vehicles.
  • Package Details: Pair
  • Additional Notes: Vehicles with independent suspension must maintain a minimum of 60mm downward suspension travel.
  • When Ordering: Select springs in accordance with your vehicles additional load.
  • Material Diameter: 17mm
  • Free Height: 405/400
  • End I/D: 145
  • Spring Rate (N/mm): 34
  • Spring Rate (Ibf/in): 194

Compatibility

  • Rear:Mitsubishi Pajero Montero NA-NG (Coil) 1988-1991 - Performance LWB
  • Mitsubishi Pajero Montero NH-NL (Coil) 6/1991-2000 - Performance LWB
  • Mitsubishi Challenger Montero Sport PA (Coil) 1998-2008 - Constant Load
  • Mitsubishi Pajero Sport 2.4L Mivec 2015+ - Performance w/ Accessories
  • All Ironman 4x4 coil springs are designed to provide a safe, comfortable ride while also providing additional ground clearance.

    Ironman 4x4 coil springs are CNC cold wound and bar peeled for maximum reliability and consistency, every coil spring is ‘shot-blasted’ to ensure long life, preset to its solid height and load tested to avoid spring sag.

    All springs are electro-static powder-coated for a gleaming appearance. Available in raised height and perfectly matched to Ironman 4x4 Shock Absorbers.

    • Quantity Required: 1
    • Estimated Lift: 40mm
    • Additional Load: Pajero 0-200kg, Challenger 200-400kg, Pajero Sport 15+ 250-500kg
    • 1988-2000 Pajero: Suits long wheel base vehicles or constant load short wheel base vehicles.
    • Package Details: Pair
    • Additional Notes: Vehicles with independent suspension must maintain a minimum of 60mm downward suspension travel.
    • When Ordering: Select springs in accordance with your vehicles additional load.
    • Material Diameter: 17mm
    • Free Height: 405/400
    • End I/D: 145
    • Spring Rate (N/mm): 34
    • Spring Rate (Ibf/in): 194
  • Rear:Mitsubishi Pajero Montero NA-NG (Coil) 1988-1991 - Performance LWB
  • Mitsubishi Pajero Montero NH-NL (Coil) 6/1991-2000 - Performance LWB
  • Mitsubishi Challenger Montero Sport PA (Coil) 1998-2008 - Constant Load
  • Mitsubishi Pajero Sport 2.4L Mivec 2015+ - Performance w/ Accessories
