Description

BD Diesel - 1045257

Super B Special SX-E S363 Turbo Kit - Dodge 1994-2002 5.9L

Super B Special Turbo Kit; SX-E S363; A/R Ration 0.80; Incl. Killer B Single Turbo/Downpipe V-Band Clamp/4 in. Stainless Steel Clamp/4 in. Downpipe/Oil Drain Gasket;

BD Single Turbo kits cover a range of turbos that are an easy complete bolt-on performance replacement for your OEM turbo, providing enough air for more power, response and reliability; The new SX-E turbo was designed for performance with a 360 thrust bearing and enhanced compressor wheel and housing; Larger compressor blade surface but with a smaller inducer results in quicker spooling, more flow than similar sized wheels; The high strength FMW Forged Milled Wheels are lighter and stronger and withstand higher wheel speeds ; BD exclusive feature of a heavy sprung waste-gated T3 turbine housing that mounts onto stock exhaust manifolds; BD's HD Waste gate and bracket holds boost and prevents over speed damage; Turnbuckle Boost Control allows for ease of adjustment for altitude and extreme tuning; Kit comes with downpipe, V-band clamp, band clamp; Comp Wheel: 63mm 2.48in; Turbine Wheel: 76mm 2.99in; A/R Ration: 0.80; Flow: 79 Lb/min; Approximate rated 550hp (depending on truck configuration)

  • BD Single Turbo kits cover a range of turbos that are an easy complete bolt-on performance replacement for your OEM turbo, providing enough air for more power, response and reliability
  • The SX-E turbo was designed for performance with a 360 thrust bearing and enhanced compressor wheel and housing
  • Larger compressor blade surface but with a smaller inducer results in quicker spooling, more flow than similar sized wheels
  • The high strength FMW Forged Milled Wheels are lighter and stronger and withstand higher wheel speeds
  • BD exclusive feature of a heavy sprung waste-gated T3 turbine housing that mounts onto stock exhaust manifolds
  • BD's HD Waste gate and bracket holds boost and prevents over speed damage
  • Turnbuckle Boost Control allows for ease of adjustment for altitude and extreme tuning
  • Kit comes with downpipe, V-band clamp, band clamp
  • Comp Wheel: 63mm 2.48in
  • Turbine Wheel: 80mm 3.15in
  • A/R Ratio: 0.80
  • Flow: 79 Lb/min
  • Approximate rated 550hp (depending on truck configuration)

Category: Single Turbo Performance
Engine: 5.9L Cummins 98.5-02 24-Valve
Make: Dodge
Suggested Product: 1453521

Compatibility

  • 1994-2002 Dodge Ram 2500 Base L6.-cc
  • 1994-2002 Dodge Ram 2500 Base V8.-cc
  • 1994-2002 Dodge Ram 3500 Base L6.-cc
  • 1994-2002 Dodge Ram 3500 Base V8.-cc

BD Diesel - 1045257

Super B Special SX-E S363 Turbo Kit - Dodge 1994-2002 5.9L

Super B Special Turbo Kit; SX-E S363; A/R Ration 0.80; Incl. Killer B Single Turbo/Downpipe V-Band Clamp/4 in. Stainless Steel Clamp/4 in. Downpipe/Oil Drain Gasket;

BD Single Turbo kits cover a range of turbos that are an easy complete bolt-on performance replacement for your OEM turbo, providing enough air for more power, response and reliability; The new SX-E turbo was designed for performance with a 360 thrust bearing and enhanced compressor wheel and housing; Larger compressor blade surface but with a smaller inducer results in quicker spooling, more flow than similar sized wheels; The high strength FMW Forged Milled Wheels are lighter and stronger and withstand higher wheel speeds ; BD exclusive feature of a heavy sprung waste-gated T3 turbine housing that mounts onto stock exhaust manifolds; BD's HD Waste gate and bracket holds boost and prevents over speed damage; Turnbuckle Boost Control allows for ease of adjustment for altitude and extreme tuning; Kit comes with downpipe, V-band clamp, band clamp; Comp Wheel: 63mm 2.48in; Turbine Wheel: 76mm 2.99in; A/R Ration: 0.80; Flow: 79 Lb/min; Approximate rated 550hp (depending on truck configuration)

  • BD Single Turbo kits cover a range of turbos that are an easy complete bolt-on performance replacement for your OEM turbo, providing enough air for more power, response and reliability
  • The SX-E turbo was designed for performance with a 360 thrust bearing and enhanced compressor wheel and housing
  • Larger compressor blade surface but with a smaller inducer results in quicker spooling, more flow than similar sized wheels
  • The high strength FMW Forged Milled Wheels are lighter and stronger and withstand higher wheel speeds
  • BD exclusive feature of a heavy sprung waste-gated T3 turbine housing that mounts onto stock exhaust manifolds
  • BD's HD Waste gate and bracket holds boost and prevents over speed damage
  • Turnbuckle Boost Control allows for ease of adjustment for altitude and extreme tuning
  • Kit comes with downpipe, V-band clamp, band clamp
  • Comp Wheel: 63mm 2.48in
  • Turbine Wheel: 80mm 3.15in
  • A/R Ratio: 0.80
  • Flow: 79 Lb/min
  • Approximate rated 550hp (depending on truck configuration)

Category: Single Turbo Performance
Engine: 5.9L Cummins 98.5-02 24-Valve
Make: Dodge
Suggested Product: 1453521

  • 1994-2002 Dodge Ram 2500 Base L6.-cc
  • 1994-2002 Dodge Ram 2500 Base V8.-cc
  • 1994-2002 Dodge Ram 3500 Base L6.-cc
  • 1994-2002 Dodge Ram 3500 Base V8.-cc
